B&R Digital Counter Module X20DC1176 Absolute Encoder

B&R Digital Counter Module X20DC1176 Absolute Encoder

    The B&R Digital Counter Module X20DC1176 is an advanced industrial automation solution designed for precise counting and monitoring applications in manufacturing environments. It offers high reliability and robust performance, making it ideal for use in machinery control systems.

Module Type:Digital Counter Module

Product ID:X20DC1176

Inputs:1 SSI absolute encoder, 5VDC

Outputs:N/A

Monitoring Capabilities:Data signal monitoring, 2 additional inputs

Power Supply:Nominal voltage: 24 VDC, Input voltage: 24 VDC -15% / +20%

Status Indicators:I/O function per channel, operating state, module status

Power Consumption:Bus: 0.01 W, Internal I/O: 1.1 W

Connection Type:3-wire connections

    This advanced digital counter module is specifically designed for integration within industrial control systems. Featuring a single SSI absolute encoder input, it provides precise and reliable measurements critical for various automation processes. The module supports two additional inputs for encoder power supply, ensuring robust operation in diverse environments. With NetTime timestamp capabilities, it enables detailed logging of counter changes, enhancing system diagnostics and maintenance. The power consumption is minimal, contributing to energy efficiency. Operable in a wide range of temperatures, this module is perfect for challenging industrial settings. Its design includes clear status indicators for easy monitoring of I/O functions, operating state, and overall module status. Ideal for engineers and technicians seeking precision and reliability in their automation solutions.
