Emerson IC200ALG240CA Analog Input Module, 8 Channel Isolated Voltage/Current Input, 16-bit Precision, Conformal Coated

Emerson IC200ALG240CA Analog Input Module, 8 Channel Isolated Voltage/Current Input, 16-bit Precision, Conformal Coated

    The Emerson IC200ALG240CA Analog Input Module is designed for industrial control systems requiring high precision and reliability. It offers 8-channel isolated analog input capabilities for voltage and current signals, ensuring accurate readings and improved system performance. This module is ideal for applications in manufacturing, process control, and automation industries.

Manufacturer:Emerson

Model:IC200ALG240CA

Module Type:Analog Input I/O Module

Channel Count:8 Channels

Resolution:16 Bit

Voltage Range:0-10V DC

Current Range:0-20mA

Isolation Voltage:1500V AC

Operating Temperature:-40°C to +85°C

Power Supply:24V DC

Conformal Coated:Yes

Weight:0.5 kg

Dimensions:100mm x 100mm x 50mm

    This robust Emerson IC200ALG240CA Analog Input I/O Module is specifically engineered to provide high accuracy and reliable performance in challenging industrial environments. The module supports both voltage and current inputs, with a resolution of 16 bits for precise measurement. Each channel is isolated from the others and the ground, ensuring minimal interference and noise. With a conformal coating, this module is protected against dust, moisture, and corrosive substances, making it ideal for use in harsh conditions.

    The module operates within a wide temperature range (-40°C to +85°C), providing flexibility for deployment in various climates. It requires a 24 VDC power supply, which can easily be integrated into existing systems. The lightweight design (approximately 137g) makes installation straightforward and reduces the strain on mounting structures.

    This module is certified by CE, UL, and CSA, ensuring compliance with international safety and quality standards. It is widely used in industries such as manufacturing, energy, and process control, where precise monitoring and control are essential.

    To install, simply connect the module to your existing PLC system and configure the settings through the programming interface. The user-friendly design ensures quick setup and maintenance.
