GE 22D-D017N104 Graphic Control Symbol
The GE 22D-D017N104 Graphics Symbol is designed for industrial control systems. It plays a critical role in providing clear and concise symbols for control panel designs, enhancing operator understanding and system efficiency.
Module Type:Graphic Symbol
Model Number:22D-D017N104
Brand:Manufacturer’s Brand Name
Dimensions:Width: 10 cm, Height: 5 cm, Depth: 2 cm
Weight:0.3 kg
Material:High-grade plastic
Color:White with blue symbols
Compatibility:Compatible with most control panels and industrial displays
Operating Temperature Range:-20°C to +60°C
This Graphics Symbol from General Electric is an essential component for any control system setup. Designed for use in industrial environments, it ensures high durability and reliable performance.
With its detailed and precise graphics, the symbol facilitates quick identification and enhances the safety and efficiency of your operations.
Crafted from high-quality plastic, this symbol offers resistance to wear and tear, making it suitable for long-term use under harsh conditions.
Its compact dimensions make it easy to install on control panels without requiring extensive space.
Installation is straightforward, simply attach the symbol to the designated area on your control panel with adhesive or screws for secure attachment.
