GE 369-HI-RM-0-E-0-E: Comprehensive Motor Protection and Monitoring

GE 369-HI-RM-0-E-0-E: Comprehensive Motor Protection and Monitoring

    The GE 369-HI-RM-0-E-0-E Motor Management Relay combines advanced metering capabilities with event reporting, waveform capture, and data logging to enhance motor performance and reliability. Ideal for safeguarding medium-sized motors and their associated equipment.

Control Power nominal:20 VA

Control Power maximum:65 VA

Control Power Input Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

Dimensions:approx. 12 in H x 5 in W x 8 in L

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:I

# of Digital/Switch Inputs:6 optically isolated

Ambient Humidity Maximum:Up to 95% non condensing

Fuse:3.15 A H 250 V

Maximum Altitude:2000 m (max)

Phase Current Inputs:1 A and 5 A secondary

# of Recordable Events:last 512 events

Communications:RS232 port, RS485 port

Waveform Capture Length:3 buffers containing 16 cycles of all current and voltage channels

Weight:approx. 10 lbs

    The GE 369-HI-RM-0-E-0-E is engineered for medium-sized motors and their associated equipment, providing unparalleled protection and control.

     With integrated metering and twelve RTD inputs, this relay monitors critical parameters to enhance operational efficiency.

     Its waveform capture, event reports, and data logging features offer deep insights into motor performance, aiding in predictive maintenance.

     The relay supports multiple input ranges, ensuring compatibility across diverse industrial environments.

     Additionally, its robust design and extensive communication capabilities make it an ideal choice for modern industrial automation systems.
