GE IS200TRLYH1BGF Control System – Relay Terminal Board

GE IS200TRLYH1BGF Control System – Relay Terminal Board

    The IS200TRLYH1BGF is a termination relay card designed for General Electric’s Mark VI series, specifically tailored for controlling gas and steam turbines. It ensures reliable performance and precise control in industrial applications.

Product Model:IS200TRLYH1BGF

Manufacturer:General Electric

Series:Mark VI

Dimensions:33 cm x 17.8 cm x 5.5 cm

Weight:1.42 kg

Terminal Blocks:Two long black terminal blocks with 24 numbered terminals each

Relays:Six black relays with transparent plastic covers

Transistors:Six black transistors positioned on either side of the relays

    The GE IS200TRLYH1BGF is a high-quality relay terminal board designed for industrial control systems. Built by General Electric, this board ensures efficient and reliable relay operations. Featuring two long black terminal blocks, each housing 24 terminals for a total of 48 terminals, this board facilitates complex wiring tasks with ease. The central area is populated by relays that are crucial for signal switching within the system, ensuring smooth operation. Additionally, six black transistors are positioned strategically on either side of the relays, enhancing the board’s capability to handle significant electrical loads. Designed with durability in mind, the transparent plastic covers over the relays allow for easy monitoring of their status during operation. This relay terminal board is ideal for those seeking robust and dependable performance in their control systems.
