GE L90-W03-HKH-F8L-H6P-L6C-N6C-S6C-U6L-W7G: Advanced Line Protection & Automation Module
The GE L90-W03-HKH-F8L-H6P-L6C-N6C-S6C-U6L-W7G is a sophisticated line protection relay designed for power system applications. It provides comprehensive monitoring, protection, and measurement functions for electrical networks.
# of FlexElements:8
Maximum Altitude:2000 m
Phasor Measurement Accuracy:±5° (angle) and ±5% (magnitude)
RS485 Port Isolation:2 kV
RTD Input Sensing Current:5 mA
Event Recording Time-Tagging:to 1 microsecond
Overvoltage Category:II
Pollution Degree:II
Ambient Humidity:up to 95%
Solid-State Output Relay Max Voltage:265 V DC
Watt-Hours Accuracy:±2.0% of reading
The GE L90-W03-HKH-F8L-H6P-L6C-N6C-S6C-U6L-W7G is an advanced industrial line protection relay, offering unparalleled reliability and accuracy in power systems. Designed for monitoring and safeguarding critical electrical infrastructure, this relay is equipped with 8 FlexElements, providing customizable protection settings for diverse applications. With an operating time of less than 30 ms at 60 Hz, it ensures rapid response to disturbances. Its robust construction supports operation up to an altitude of 2000 meters and is capable of withstanding harsh environmental conditions. The phasor measurement calibration ensures precise angle and magnitude readings, contributing to accurate system monitoring. The RS485 port isolation and passive DCMA input type enhance its compatibility and operational stability. With an ingress protection rating of IP20 front and IP10 back, the relay is protected against dust and water ingress. The solid-state output relay offers a maximum voltage of 265 V DC, making it suitable for a wide range of industrial applications. This relay also boasts a high watt-hours accuracy of ±2.0%, ensuring reliable energy measurements. The alphanumeric display provides clear and easy-to-read information, enhancing operational efficiency.
