GE Multilin 745-W3-P5-G5-HI-R-E Transformer Management Relay
The General Electric SR745-W3-P5-G5-HI is a state-of-the-art Transformer Management Relay designed to protect transformers, autotransformers, and reactors. It features real-time adaptive protection mechanisms, extensive monitoring capabilities, and high control power to ensure optimal performance and longevity.
Weight:4.8 kg
Voltage Input Burden:Less than 0.025 VA at 120 V
Source VT:2 to 600 kV / 60 to 120 V
Number of Logic Inputs:16
Manufacturer:General Electric Multilin
Fuse Current Rating:3.15 A
Control Power Range:90 to 300 VDC; 70 to 265 VAC at 48 to 62 Hz
Harmonic Monitoring:Monitors individual harmonics and total harmonic distortion
Real-Time Error Correction:Adaptive correction for CT ratio mismatch
The GE Multilin 745-W3-P5-G5-HI Transformer Management Relay is an indispensable tool for managing and protecting transformers of any size.
Designed with a wide range of adaptive capabilities, this relay can operate as a standalone unit or alongside other relays in the Multilin 745 series.
The enhanced 40-character display allows for clear and detailed setpoint entry, making it easy to configure and monitor the system.
The robust construction ensures durability in harsh industrial environments, with a height of 9 inches, width of 7 inches, and depth of 7 ⅛ inches.
The front of the case includes several LEDs that provide real-time status updates and error alerts.
With its user-friendly interface and high control power, the GE Multilin 745-W3-P5-G5-HI is perfect for ensuring reliable operation of your power systems.
