GE SR745-W2-P1-G1-HI-E-H Transformer Management & Safeguard Relay
The Multilin 745-W2-P1-G1-HI-E-H is designed for managing and safeguarding transformers, autotransformers, and reactors. It features adaptive protection mechanisms and enhanced display capabilities for better operation and maintenance.
Winding Per Phase:2
Resistant Temperature Device (RTD) Type:3 wire; 100 Ω Nickel, 120 Ω Nickel, 100 Ω Platinum
Analog Output Maximum Load:10 kΩ at 0 to 1 mA, 600 Ω at 4 to 20 mA
Maximum Continuous Voltage Output:273 V
Display Type:40 character Enhanced LCD
Dimensions:Height: 9 inches, Width: 7 inches, Depth: 7 ⅛ inches
Control Power Range:90 to 300 V DC; 70 to 265 V AC at 48 to 62 Hz
The GE SR745-W2-P1-G1-HI-E-H Transformer Protection System is an innovative solution designed to optimize the performance of transformers, autotransformers, and reactors.
With its advanced adaptive features like dynamic CT ratio mismatch correction and overexcitation protection, it ensures that your systems operate safely and efficiently.
The large 40-character enhanced LCD display and expanded keypad make it easy to manually enter setpoints, enhancing usability.
Mountable on a standard 19” panel, this system integrates seamlessly into existing infrastructure.
Real-time alerts provided through the front panel LEDs keep you informed about the status and any errors, allowing for immediate corrective action.
Designed for durability and reliability, the SR745-W2-P1-G1-HI-E-H is a must-have for anyone looking to safeguard their critical electrical assets.
