General Electric DS200DCFBG1BJB DC Power Supply Board for EX2000 Applications
The DS200DCFBG1BJB is a high-performance DC Power Supply and Feedback Board designed by General Electric for EX2000 and various IGBT drive applications including DC2000, FC2000, GF2000, ME2000, CB2000, and AC2000. It provides reliable power to drives and enclosure fans, ensuring smooth operation of industrial control systems.
Manufacturer:General Electric
Model Number:DS200DCFBG1BJB
Module Type:DC Power Supply and Feedback
Power Output:Varies per application
Input Voltage Range:90-265VAC
Frequency Range:47-63Hz
Protection Features:Integrated Fuses
Diagnostic Indicators:Two LEDs and One Neon Indicator
Jumpers:Twelve
DIP Switches:Seven
Compatibility:EX2000, DC2000, FC2000, GF2000, ME2000, CB2000, AC2000 IGBT drive applications
The DS200DCFBG1BJB is an essential component for industrial automation systems.
Designed specifically for applications requiring precise power management and feedback control, this board integrates seamlessly into systems for steam, wind, and gas turbines.
Its robust design includes multiple configuration options through twelve jumpers and seven DIP switches, allowing users to tailor the board to their specific needs.
Diagnostic features such as two LED and one neon status indicators provide real-time feedback on the health and status of the board, while three integrated protective fuses safeguard against power interruptions.
The inclusion of five test points facilitates easy maintenance and troubleshooting, ensuring the board operates at peak efficiency.
As part of the Mark V Series, the DS200DCFBG1BJB leverages General Electric’s patented Speedtronic control system technology, ensuring reliability and performance excellence.
