NI PXI-2503 High-Density Digital I/O Module for Industrial Automation

NI PXI-2503 High-Density Digital I/O Module for Industrial Automation

    The NI PXI-2503 is a high-performance digital I/O module designed for industrial automation applications. It offers fast data transfer rates and robust reliability, making it ideal for test and measurement systems where precision and speed are critical.

Brand:National Instruments

Model:PXI-2503

Series:PXI-2503

Order Number:185450D-01

Custom Processing:Yes

Item No.:PXI-2503

Certified Product:PXI-2503 185450D-01

Operating Voltage Range:±100 V

Current Measurement Range:±10 A

Resistance Measurement Range:0 Ω to 10 MΩ

Accuracy:±0.01% of reading ±1 digit

Sampling Rate:Up to 1000 samples/s

Interface:PXI Express (PCIe)

    The National Instruments PXI-2503 is a high-speed digital I/O module designed specifically for use in PXI or PXI Express systems. With its 32 differential channels, this module supports data transfer rates up to 20 MHz per channel, enabling rapid and precise communication in demanding industrial environments. Its compatibility with both PXI and PXI Express systems ensures flexibility and scalability in system design. Equipped with a robust 68-pin VHDCI connector, the PXI-2503 provides secure and reliable connections. The module operates within a wide temperature range from -40°C to 85°C, making it suitable for harsh industrial settings. Additionally, the PXI-2503 is powered by ±5 V and ±12 V, ensuring stable operation under various conditions. Ideal for test and measurement systems, this module offers unparalleled performance and reliability.
