Pacific Scientific E21SCHT (3805) Precision Stepper Motor

Pacific Scientific E21SCHT (3805) Precision Stepper Motor

    The Pacific Scientific E21SCHT (3805) stepper motor is designed for high precision and reliable operation in various industrial applications. Ideal for positioning systems and automated machinery requiring accurate motion control.

Manufacturer:Pacific Scientific

Model:E21SCHT (3805)

Motor Type:Stepper Motor

Rated Torque:1.5 Nm

Step Angle:1.8°

Voltage Range:24-48V DC

Current Rating:3.0 A

Phase Count:4 Phase

Rotor Inertia:0.0001 kg·m²

Frequency Range:0-5000 Hz

Operating Temperature:-20°C to +85°C

Protection Rating:IP65

    The Pacific Scientific E21SCHT (3805) stepper motor is built with robust materials ensuring durability and longevity. Its high precision design makes it perfect for applications demanding accurate positioning and motion control. This motor operates within a wide voltage range from 24V to 80V DC, providing flexibility for various industrial setups. With a step angle of 1.8° per step, it ensures precise movement, making it suitable for use in robotics, packaging machines, and other automation equipment. The E21SCHT (3805) supports speeds ranging from 100 to 3000 RPM, allowing for versatile operation across different machinery requirements. The compact size and lightweight design make it easy to integrate into existing systems without compromising on performance. For installation, follow the manufacturer’s guidelines to ensure proper alignment and optimal performance.
