Schneider X80-Q BMXEHC0200H Enhanced 2-Channel High-Speed Counter Module, 60KHz, 6x24VDC Input/2 Transistor Output, 4 Counting Modes & 4 Measurement Modes with PWM, Terminal Block BMXXTSHSC20

Schneider X80-Q BMXEHC0200H Enhanced 2-Channel High-Speed Counter Module, 60KHz, 6x24VDC Input/2 Transistor Output, 4 Counting Modes & 4 Measurement Modes with PWM, Terminal Block BMXXTSHSC20

    The Schneider X80-Q BMXEHC0200H Enhanced 2-Channel High-Speed Counter Module is designed for industrial automation applications requiring high-speed counting capabilities. It supports up to 60KHz per channel and includes four distinct counting modes and four measurement modes, along with PWM functionality, making it an essential component for precision control systems.

Manufacturer:Schneider Electric

Model Number:BMXEHC0200H

Module Category:High-Speed Counter Module

Channels:2

Counting Frequency:Up to 60kHz per channel

Input Voltage:6x24VDC

Output Type:2x Transistor Output

Counting Modes:4

Measurement Modes:4

PWM Support:Yes

Terminal Block:BMXXTSHSC20

Environmental Resistance:Conformal Coated PCB

    This Schneider X80-Q BMXEHC0200H is a robust high-speed counter module engineered for precise control and measurement tasks in industrial settings. Its core design focuses on reliability and versatility, offering two independent counting channels capable of handling up to 60KHz per channel. The module is equipped with four distinct counting modes and four measuring modes, providing flexibility for various application scenarios. Moreover, the inclusion of Pulse Width Modulation (PWM) functionality enhances its adaptability to complex control systems.

    Crafted with durability in mind, the module utilizes a conformal coated PCB to withstand harsh environmental conditions. Each channel supports 24VDC input and provides 2 transistor outputs, ensuring efficient signal transmission. This combination of features makes the Schneider X80-Q BMXEHC0200H a versatile solution for automation and control systems.

    Installation is straightforward, thanks to the included BMXXTSHSC20 terminal block, which simplifies wiring and enhances system integration. The module’s compact design facilitates easy installation without compromising performance or functionality. Ideal for applications requiring accurate and rapid counting and measurement, this module stands out for its reliability and efficiency.
